Der RPL32WD ist ein Intelligenter Wi-Fi Powermonitor zum Einklinken in 3-phasige 32 Ampere Versorgungsstränge.
Spannung/Strom -Anzeige zum Einschleifen in 3-phasige Versorgungsstränge
Spezifische Merkmale:
- Messung aller 3x Außenleiter
- WatchDog Funktion bei Grenzwerten
- Leistungsmessung auf jedem Kanal
- Webserver zum Monitoren und Konfigurieren
- Wi-Fi, MQTT, Bluetooth...
- Leistungsmessung mit Datenspeicherung
- Intelligente Zeitpläne, Skripting, Webhooks
- 3x Digitalanzeige Voltmeter Amperemeter, blau für jede Phase
- Spannungsmessbereich: 60 V bis 500 V, Messgenauigkeit ±1
- Strommessung: 0 bis 100 A, Messgenauigkeit ±1
- mit RigPort RPL-Clamps schnell und einfach montierbar
- 1x M10, 2x M4
- Shelly Pro 3EM
Anschlüsse:
- 1x CEE32-5p-In
- 1x CEE32-5p-Through Out
- 1x Ethercon
Dokumentation:
user manual
Technische Daten:
# Hier ist ein YAML-Beispielcode ```yaml title: Shelly 3EM Pro Dashboard views: - title: Shelly 3EM Pro path: shelly_3em_pro cards: - type: grid title: Spannungen und Ströme columns: 3 square: false cards: # Phase 1: Spannung - type: gauge entity: sensor.shelly_3em_pro_voltage_phase_1 name: Spannung L1 unit: "V" min: 207 max: 253 severity: green: 220 yellow: 240 red: 253 theme: default # Phase 2: Spannung - type: gauge entity: sensor.shelly_3em_pro_voltage_phase_2 name: Spannung L2 unit: "V" min: 207 max: 253 severity: green: 220 yellow: 240 red: 253 theme: default # Phase 3: Spannung - type: gauge entity: sensor.shelly_3em_pro_voltage_phase_3 name: Spannung L3 unit: "V" min: 207 max: 253 severity: green: 220 yellow: 240 red: 253 theme: default # Phase 1: Strom - type: gauge entity: sensor.shelly_3em_pro_current_phase_1 name: Strom L1 unit: "A" min: 0 max: 63 severity: green: 0 yellow: 50 red: 63 theme: default # Phase 2: Strom - type: gauge entity: sensor.shelly_3em_pro_current_phase_2 name: Strom L2 unit: "A" min: 0 max: 63 severity: green: 0 yellow: 50 red: 63 theme: default # Phase 3: Strom - type: gauge entity: sensor.shelly_3em_pro_current_phase_3 name: Strom L3 unit: "A" min: 0 max: 63 severity: green: 0 yellow: 50 red: 63 theme: default # Graph der Ströme für Phase 1 - type: history-graph entities: - entity: sensor.shelly_3em_pro_current_phase_1 hours_to_show: 24 refresh_interval: 300 name: Stromverlauf L1 # Graph der Ströme für Phase 2 - type: history-graph entities: - entity: sensor.shelly_3em_pro_current_phase_2 hours_to_show: 24 refresh_interval: 300 name: Stromverlauf L2 # Graph der Ströme für Phase 3 - type: history-graph entities: - entity: sensor.shelly_3em_pro_current_phase_3 hours_to_show: 24 refresh_interval: 300 name: Stromverlauf L3 ```
Abmessungen: | 321x90x100mm |
---|---|
Gewicht: | 1,6Kg |
HS Code: | 85369010 |
Leiterquerschnitt: | 6mm² |
Material: | Stahlblech |
Maximale Stromstärke: | 16A |
Maximale Temperatur: | 55°C |
Schutzklasse: | IP54 |
